Log band saw
HBBS 660 G
Precise saw cuts when ripping round timber
3.329,00
EUR excl. Tax / pc(s).
3.961,51 EUR incl. 19% Tax / pc(s).
3.961,51 EUR incl. 19% Tax / pc(s).
Promotional price *
3.159,00 EUR excl. Tax / pc(s).3.759,21 EUR incl. 19% Tax / pc(s).
Prices are recommended retail prices. Retailer prices may vary.
* Promotional price valid until 28.02.2025 in Germany.
Art.-No. 5670664
Are you interested in this product?
Put a request
Find Trader
Productdetails
- Solid cast wheels driven by an 11 kW petrol engine
- Manual adjustment of cutting height via hand crank
- Robust and torsion-resistant steel construction
- Simple operation with the aid of a manual saw feed
- Stable clamping of the log thanks to adjustable tips
- Precise cuts thanks to adjustable saw blade guide
- Low friction between saw blade and wood thanks to integrated blade lubrication
- The side-mounted chip removal ensures a clean working area
- Any cutting length thanks to bed extensions available as accessories
- Suitable for softwood and hardwood
| Cutting ranges | |
|---|---|
| Max. trunk diameter | 660 mm |
| Max. cutting width | 530 mm |
| Cutting length max. | 3200 mm |
| Passage over saw band | 190 mm |
| Dimensions and weights | |
|---|---|
| Length approx. | 4000 mm |
| Width/depth approx. | 2150 mm |
| Height approx. | 2000 mm |
| Weight approx. | 340 kg |
| Noise emission | |
|---|---|
| Sound power level | 96,1 dB(A) |
| Saw band | |
|---|---|
| Speed(s) | 20 m/s |
| Length | 3650 mm |
| Width | 34 mm |
| Strength | 1 mm |
| VPE | 1 |
Unit: pc(s).
Packaging unit: 1
Packaging unit: 1
| Drive type | Gasoline |
| Material frame construction | Steel |
| Feed rate | manually |
