Wide belt sander
MBBS 1350-17 RX
for deburring and finish grinding
Price upon request
Prices are recommended retail prices. Retailer prices may vary.
Art.-No. 4403500
Are you interested in this product?
Put a request
Find Trader
Productdetails
- For deburring flat components e.g. after laser cutting or punching
- Large working width with up to 1350 mm
- Conveyor table with profile foconveyor belt for optimum hold during processing
- NC control with 8" touch screen
- For deburring flat components e.g. after laser cutting or punching
- Large working width with up to 1350 mm
- Conveyor table with profile conveyor belt for optimum hold during processing
| Application scope | |
|---|---|
| Deburring | ✔ |
| Edge rounding | ✔ |
| Remove oxide layer | ✔ |
| Blank grinding | ✔ |
| Finish grinding for visible surfaces | ✔ |
| Dimensions and weights | |
|---|---|
| Space requirement | 1900 x 1900 mm |
| Length approx. | 1850 mm |
| Width/depth approx. | 1800 mm |
| Height approx. | 2200 mm |
| Weight approx. | 1500 kg |
| Electrical Data | |
|---|---|
| Input power | 17 kW |
| Supply voltage | 400 V |
| Mains frequency | 50 Hz |
| Extraction | |
|---|---|
| Extraction duct nominal width outside | 120 mm |
| Extraction duct nominal width inside | 2 |
| Noise emission | |
|---|---|
| Sound power level Lw (idling without extraction unit) | 77 dB(A) |
| Pneumatic connection | |
|---|---|
| Operating supply pressure | 6 bar |
| Sanding machine | |
|---|---|
| Max. sanding width | 1350 mm |
| Sanding belt length | 2220 mm |
| Sanding belt width | 1370 mm |
| Grinding disc diameter | 115 mm |
| Circulation speed of grinding belt unit | 18 m/s |
| Circulation speed of fan grinder unit | 10 m/s |
| Contact wheel diameter | 180 mm |
| Work table | |
|---|---|
| Work table width | 1400 mm |
| Table height adjustment stroke | 170 mm |
| Table cross stroke | 170 mm |
| Table load max. | 150 kg |
| Table height min. | 780 mm |
| Table height max. | 950 mm |
| Feed speed | 6.5 m/s |
| Workpiece | |
|---|---|
| Workpiece height min. | 0,5 mm |
| Workpiece height max. | 170 mm |
| VPE | 1 |
Unit: pc(s).
Packaging unit: 1
Packaging unit: 1
- 1 x sanding belt with paper backing K120
- 1 x Scotch brush
| Sanding belt unit | ✔ |
| Fan grinder unit | ✔ |
| Work table height adjustment | joystick |
