MSBM 1520-17 PRO SH for sheet thickness steel up to 1.75 mm

Heavy-duty design with motorized clamping of the workpiece

19.390,00 EUR excl. Tax / pc(s).
23.074,10 EUR incl. 19% Tax / pc(s).

Prices are recommended retail prices. Retailer prices may vary.

Sicherheits- und Warnhinweise

Safety and warning notices

Art.-No. 3779080

Are you interested in this product?

Put a request

Find Trader

Productdetails

Foot operated
Heavy, compact welded construction
Powerful drive by Lenzemotors
With continuous sharp bending bar
In series with manual adjustment of the bending angle
Especially low-maintenance
The workpiece is clamped by a motorized mechanism
S-models with segmented upper tools
SH-models with high, segmented casting foot tools

Available on request

Other models
Standard tools hardened
Hardened sharp bending bar and bending bar
Segmented tools and hardened bending bar
Segmented casting foot tools and bending bar hardened

Data sheets
Sicherheits- und Warnhinweise
Safety and warning notices

Max. working width	1520 mm
Max. passageway between top + bottom beam	60 mm
Segmentation	25-30-35-40-45-50-75-100-150-220-250-500 mm
VPE	1

Bending capacity
400N/mm²	1.75 mm
Explanation 400N/mm²	Bending capacity VA: factor 0.65; bending capacity aluminium: factor 1.4; optional tool required for bending VA

Dimensions and weights
Length approx.	2150 mm
Width/depth approx.	700 mm
Height approx.	1100 mm
Weight approx.	810 kg

Electrical Data
Beam motor intput	0.37 kW
Bending motor input	0.75 kW

Unit: pc(s).
Packaging unit: 1
