Motorized ring bending machine
PRM 35 F
Can be used horizontally and vertically for profiles, tubes and solid material
4.449,00
EUR excl. Tax / pc(s).
5.294,31 EUR incl. 19% Tax / pc(s).
5.294,31 EUR incl. 19% Tax / pc(s).
Promotional price *
3.999,00 EUR excl. Tax / pc(s).4.758,81 EUR incl. 19% Tax / pc(s).
Prices are recommended retail prices. Retailer prices may vary.
* Promotional price valid until 31.08.2025 in Germany.
Art.-No. 3812035
Are you interested in this product?
Put a request
Find Trader
Productdetails
- heavy welded steel construction
- horizontal and vertical work possibility
- lower rollers driven by a motor
- Rolls are hardened
- Steel shafts, hardened and ground
- Delivery via upper roller
- lateral straightening rollers, infinitely adjustable
- powerful 400 volt engine
- Left / right rotation by foot pedal
| Bending performances profile type optional | |
|---|---|
| Square tube dimensions [1] | 50 x 3 mm |
| Square tube min. bending Ø [1] | 1700 mm |
| Square tube dimensions [2] | 40 x 3 mm |
| Square tube min. bending Ø [2] | 600 mm |
| Square tube heavy axis dimensions bending Ø [1] | 70 x 30 x 2 mm |
| Square tube heavy axis min. bending Ø [1] | 1200 mm |
| Square tube heavy axis dimensions bending Ø [2] | 50 x 40 x 3 mm |
| Square tube heavy axis min. bending Ø [2] | 1200 mm |
| Round tube dimensions [1] | 50.8 x 2.9 mm |
| Round tube min. bending Ø [1] | 1000 mm |
| Round tube dimensions [2] | 25.4 x 2.3 mm |
| Round tube min. bending Ø [2] | 350 mm |
| Round profile dimensions [1] | 35 mm |
| Round profile min. bending Ø [1] | 600 mm |
| Round profile dimensions [2] | 30 mm |
| Round profile min. bending Ø [2] | 400 mm |
| isosceles angle profile outside dimensions [1] | 50 x 50 x 5 mm |
| isosceles angle profile outside leg min. bending Ø [1] | 800 mm |
| isosceles angle profile outside dimensions [2] | 40 x 40 x 5 mm |
| isosceles angle profile outside leg min. bending Ø [2] | 600 mm |
| isosceles angle profile inside dimensions [1] | 50 x 50 x 6 mm |
| isosceles angle profile inside leg min. bending Ø [1] | 1000 mm |
| isosceles angle profile inside dimensions [2] | 30 x 30 x 3 mm |
| Explanations for bending performance, profile type optional | The performance data apply to material with a max. Yield strength of 24kg / mm². Bending power at VA: factor 0.7 |
| Bending performances profile type standard | |
|---|---|
| Square material dimensions [1] | 35 mm |
| Square material min. bending Ø [1] | 900 mm |
| Square material dimensions [2] | 20 mm |
| Square material min. bending Ø [2] | 300 mm |
| Flat material light axis dimensions bending Ø [1] | 100 x 15 mm |
| Flat material light axis min. bending Ø [1] | 450 mm |
| Flat material light axis dimensions bending Ø [2] | 60 x 10 mm |
| Flat material light axis min. bending Ø [2] | 350 mm |
| Flat material heavy axis dimensions bending Ø [1] | 60 x 10 mm |
| Flat material heavy axis min. bending Ø [1] | 500 mm |
| Flat material heavy axis dimensions bending Ø [2] | 40 x 10 mm |
| Flat material heavy axis min. bending Ø [2] | 400 mm |
| UPN profile top rib dimensions [1] | 60 x 7 mm |
| T profile top rib min. bending Ø [1] | 700 mm |
| UPN profile top rib dimensions [2] | 50 x 6 mm |
| T profile top rib min. bending Ø [2] | 500 mm |
| Explanation for T profile rib above | Additional spacers may be required |
| UPN profile outside rib dimensions [1] | 60 x 7 mm |
| T profile outside rib min. bending Ø [1] | 700 mm |
| UPN profile outside rib dimensions [2] | 50 x 6 mm |
| T profile outside rib min. bending Ø [2] | 500 mm |
| UPN profile inside rib dimensions [1] | 60 x 7 mm |
| T profile inside rib min. bending Ø [1] | 700 mm |
| UPN profile inside rib dimensions [2] | 50 x 6 mm |
| T profile inside rib min. bending Ø [2] | 500 mm |
| UPN profile outside leg dimensions [1] | UPN 80 mm |
| UPN profile outside leg min. bending Ø [1] | 1000 mm |
| UPN profile outside leg dimensions [2] | UPN 30 mm |
| UPN profile outside leg min. bending Ø [2] | 700 mm |
| UPN profile inside leg dimensions [1] | UPN 80 mm |
| UPN profile inside leg min. bending Ø [1] | 1200 mm |
| UPN profile inside leg dimensions [2] | UPN 30 mm |
| Inside leg min. bending Ø [2] | 800 mm |
| Explanations for bending performance, profile type standard | The performance data apply to material with a max. Yield strength of 24kg / mm². Bending power at VA: factor 0.7 |
| Dimensions and weights | |
|---|---|
| Length approx. | 750 mm |
| Width/depth approx. | 1000 mm |
| Height approx. | 1400 mm |
| Weight approx. | 400 kg |
| Electrical Data | |
|---|---|
| Drive motor output | 1,5 kW |
| Supply voltage | 400 V |
| Mains frequency | 50 Hz |
| Machine data | |
|---|---|
| Shaft diameter top | 50 mm |
| Shaft diameter bottom | 50 mm |
| Roller diameter top | 155 mm |
| Roller diameter bottom | 155 mm |
| Speed | 4.5 m/min |
| VPE | 1 |
