minimax sc 4e 33 with pre-cutting device

With swiveling saw blade and anodised aluminum format sliding carriage for the discerning user

9.190,00 EUR excl. Tax / pc(s).
10.936,10 EUR incl. 19% Tax / pc(s).

Promotional price *

6.999,00 EUR excl. Tax / pc(s).
8.328,81 EUR incl. 19% Tax / pc(s).

Prices are recommended retail prices. Retailer prices may vary.
* Promotional price valid until 28.02.2025 in Germany.

Art.-No. 5504534VR

Are you interested in this product?

Put a request

Find Trader

Productdetails

The solid work table made of heavily ribbed grey cast iron and the base frame made of welded steel warranty high torsional stiffness and vibration-free work
Smooth-running and precise sliding carriage made of anodized aluminium with proven and permanently smooth-running ball contact system on hardened, 10-year warranty on wear of the guideways
Cast iron saw unit with permanently precise double swivel segment guide and zero-point swivel, 6 years Holzkraft warranty on wear of the swivel segments
Equipped with powerful three-phase motor
Saw blade tilting is indicated on a scale on the unit
Large edging frame with roller facilitates panel feeding
Angle-adjustable aluminium telescopic fence with two professional folding fences
Folding rip fence with quick clamping and fine adjustment
Standard with table extension, table extension and eccentric clamp
Made in Italy

Circular saw unit
Max. cutting width with rip fence	900 mm
Max. cross cut width left from saw blade	3200 mm
Trimming length	3260 mm
Saw blade angle	90 – 45 °
Max. cutting height 90°	100 mm
Max. cutting height 45°	70 mm
Explanation to: Max. cutting height	Independent of the scoring unit
(Main) saw blade diameter	315 mm
Explanation to: (Main) saw blade diameter	Independent of the scoring unit
(Main) saw blade speed	3800 min¯¹

Dimensions and weights
Weight approx.	489 kg

Electrical Data
Drive motor output	5.0 kW
Supply voltage	400 V
Mains frequency	50 Hz

Extraction port
Extraction port diameter bottom	120 mm
Saw blade protection extraction port diameter	60 mm

Pre-scoring unit
Diameter saw blade	100 mm
Saw blade speed	7800 min¯¹

Sliding carriage and table
Sliding carriage length	3200 mm
Sliding carriage width	360 mm
Sliding carriage height	142 mm
Table length	840 mm
Table width	560 mm
Work height	900 mm

VPE

Unit: pc(s).
Packaging unit: 1

Anodised aluminum sliding carriage
Roll of material on the boom
Saw rip fence with round bar guide
table extension
table extension
folding stops
edging shoe
Eccentric
Handle for sliding carriage
Pre-cutting device with mounting kit, saw blade 100 mm

Scoring saw unit	Driven by motor of main saw blade via flat belt, with saw blade Ø 100 mm
Anodised aluminium sliding sizing carriage	✔
Handle for sliding carriage	✔
Material roll on claming frame	✔
Saw rip fence	with round rod guide
Stops	Two professional folding stops
Clamp sleigh	✔
Eccentric clamp	✔
Table broadening	✔
Table lengthening	✔
Saw blade cover	✔
